Microcentrifuge MHM-1A
Model: MHM-1A · Category: Centrifuges
Micro-centrifuge MHM-1A is a benchtop unit with an operating speed range of 500 rpm-15000 rpm. It is equipped with a range of rotors with high speed accuracy of ± 20 rpm for precise separation of samples. Features continual operational mode avoiding unwanted intervention and shortens sample running time. Automated lid locking system ensures high safety and prevents accidental outburst.
Specifications
| Speed range | 500 rpm ~ 15000 rpm |
|---|---|
| Maximum RCF | 15100 ×g |
| Speed accuracy | ± 20 rpm |
| Time range | 30 s to 99 mins |
| Speed increment | 100 rpm |
| Maximum RCF increment | 100 ×g |
| Power (single phase) | AC110V ~ 240V, 50Hz/60Hz, 3A |
| Noise level | ≤ 56 dB |
| Acceleration or Braking time | 30s↑10s↓ |
| Dimensions | 256 x 225 x 155 mm |
| Weight | 6 kg |
Features
| Maximum speed - 15000 rpm |
| Easy viewing of cycles (LED display) |
| Rapid acceleration and braking system |
| Speed/RCF switch - regulation of cycles |
| Programmable operation - stores up to 10 programs |
| Aluminum alloy and plastic rotor (chemically resistant) |
Applications
Used for DNA separation/ isolation, molecular biology, immunology, microbiology, genomics, proteomics, biochemistry practices
Rotor Selection
| Rotor type | Max. RCF | Capacity (×12) |
|---|---|---|
| 0.2 ml | ||
| Angle rotor | 15100 ×g | 0.5 ml |
| 1.5 ml | ||
| 2.0 ml |
Safety Unit
| Serial No. | Device |
|---|---|
| 1 | Door interlock |
| 2 | Over- speed detection |
| 3 | Over- temperature detection |
| 4 | Automatic internal diagnosis |
